Ultrasonic cleaners have been widely used in various industrial sectors such as metals, electroplating, plastics, electronics, machinery, and automotive, as well as in scientific research institutions and universities
Features
• New Excitation Circuit Design: Features automatic frequency tracking for stable and reliable operation. Compared to traditional self-excited oscillation circuits, this design increases output power by over 15%
• High-Q Transducer: Achieves an electro-acoustic conversion efficiency of over 98%, with each transducer delivering 50W of power
• IGBT High-Power Module Control: Ensures powerful output, significantly extends the lifespan of ultrasonic components, and effectively protects transducers during operation. The ultrasonic generator includes a 1% fine-tuning frequency adjustment function to maximize efficiency under varying working conditions
• Premium Sheet Metal Technology & Advanced Bonding Process: Optimized circuit structure reduces operational noise by approximately 26 dB compared to conventional ultrasonic devices
• Ultrasonic Frequency: 40 kHz with auto-tracking and adaptive capabilities
• Rated Ultrasonic Power: 100‒800W, adjustable in 10% increments (0‒100%)
• Adjustable Timer: 1‒999 minutes, with patented pulse-ultrasound interval function (6s‒3s intermittent operation)
• Heating System: 100‒800W heating power, adjustable temperature range: room temperature to 80°C
• 304 Stainless Steel Tank: 1mm thick, formed via one-time stamping for durability
• 3.7-inch HD Touchscreen: Industry’s largest LCD display, showing real-time time, temperature, power, frequency, current, and countdown status
• Safety Protections: Over-current, over-voltage, and over-temperature alarm functions
• Elegant & Waterproof Panel: Made of acrylic glass for both aesthetics and functionality
Specifications
| Model | L-UCS-3L | L-UCS-6L | L-UCS-10L | L-UCS-15L | L-UCS-22.5L |
| Description | LCD Intelligent Silent Ultrasonic Cleaner,3L | LCD Intelligent Silent Ultrasonic Cleaner,6L | LCD Intelligent Silent Ultrasonic Cleaner,10L | LCD Intelligent Silent Ultrasonic Cleaner,15L | LCD Intelligent Silent Ultrasonic Cleaner,22.5L |
| Capacity (L) | 3 | 6 | 10 | 15 | 22.5 |
| Operating Frequency (kHz) | 40 | 40 | 40 | 40 | 40 |
| Power Adjustment (%) | 10-100 | 10-100 | 10-100 | 10-100 | 10-100 |
| Ultrasonic Power (W) | 100 | 150 | 200 | 300 | 500 |
| Heating Power (W) | 200 | 400 | 600 | 600 | 1000 |
| Temperature Range (°C) | RT-80 | RT-80 | RT-80 | RT-80 | RT-80 |
| Timer Range(min) | 1-999 | 1-999 | 1-999 | 1-999 | 1-999 |
| Tank Dimensions (mm) | 240×145×100 | 300×150×100 | 300×240×150 | 330×300×150 | 500×300×150 |
| Standard Accessories | Basket & Drainage Kit | ||||
| Sound-Reducing Lid, Silicone Rubber Gasket | |||||
| Control Method | Touch-Sensitive Operation | ||||
| Price | 420,000 | 532,000 | 644,000 | 910,000 | 1,190,000 |
