• Output Types: Constant Voltage, Constant Current, Constant Power
• Transparent instrument casing for clear visibility of internal structure
• LCD screen simultaneously displays voltage, current, power, and timer
• Four parallel channels for simultaneous connection to multiple electrophoresis tanks
• Programmable storage for 10 methods, each supporting up to 10 steps
• Protein function: Automatic transition from stacking gel to separating gel, reducing the hassle of manual reconfiguration（Only LP-600V）
• Auto-generation function: After selecting a constant value, the other two parameters are automatically generated, preventing human error in setting constants（Only LP-600V）
• Micro-current function: Automatically switches to micro-current after electrophoresis to prevent sample diffusion due to timed shutdown while avoiding overrun
• Safety features: Overvoltage, arcing, no-load, and load mutation monitoring; overload/short-circuit protection; leakage protection; open-circuit alarm, automatic recovery after power failure, pause/resume function
Specifications
Model | LP-300V | LP-600V | |
Description | Basic Electrophoresis Power Supply,300V,400mA,75W | Universal Electrophoresis Power Supply,600V,1200mA,500W | |
Current | Range | 5-400mA | 1-1200mA |
Resolution | 1mA | 1mA | |
Voltage | Range | 10-300V | 5-600V |
Resolution | 1V | 1V | |
Power | Range | 5-75W | 1-500W |
Resolution | 1W | 1W | |
Time range | 1min‒99h59min | ||
Dimensions | 308×242×100mm（L×W×H） | ||
Weight | 2kg | 2.6kg | |
Price | 728,000 | 1,022,000 | |
