The UV-Vis spectrophotometer is designed to meet high requirement for precision measurement in the research and production of organic chemistry, biochemistry, medical testing, food testing, environmental protection, water testing industry, etc. The latest ARM system and long optical system ensure high accuracy and good stability of the instrument. They are the best choice of high quality spectrophotometer.
Features
• Adopt high resolution (1024×768) lattice 7-inch color touch LCD display, friendly and simple operation interface
• Supports cloud storage function, which can easily realize wechat scanning, convenient for customers' application scenarios
• Adopts "shining holographic grating" high resolution C-T monochromator, and adopts 24-bit high precision AD chip, makes the economical instrument with low stray light (less than 0.1T%), high precision and high stability (0.002A)
• Powerful storage capacity, can store 500 data, 30 working curves, convenient for customers to use
• Equipped with USB interface, WIFI module and Bluetooth module. Can realize wireless Bluetooth printing; The data exported from USB flash drive can be directly opened and edited by EXCEL, which is convenient for customers
• Automatic wavelength setting, automatic light switching settings, connected to the computer software, can achieve wavelength scanning, dynamic determination, quantitative determination, nucleic acid determination, wavelength superposition, integral derivative and other advanced functions
Specifications
Model | LUV-S0302T | LUV-S1004T |
Description | UV-Vis Spectrophotometer, Bandwidth 2 nm | UV-Vis Spectrophotometer, Bandwidth 4 nm |
Optical system | Single beam, Grating 1200 lines/mm | |
WIFI | Standard | |
IoT software | Standard | |
Detector | Imported silicon photodiode | |
Wavelength range | 190-1100nm | |
Spectral bandwidth | 2.0nm | 4.0nm |
Wavelength accuracy | ±0.3nm | |
Wavelength repeatability | ≤0.1nm | ≤0.5nm |
Wavelength setting | Automatic | |
Display | High resolution 1024×768 touch screen, 7 inches | |
Photometric range | 0-200%T，-0.3-3.0A，0-9999C（0-9999F） | |
Stray light | ≤0.1%T | ≤0.2%T |
Stability | 0.001A(500nm,3min) | 0.002A(500nm,2min) |
Noise | 0.15%T | 0.2%T |
Light source | Automatic, 340mm(configurable) | |
Output | USB&Bluetooth | |
Price | 3,598,000 | 2,240,000 |
